SPECIFICATIONS

HS Code: 8528591090

Screen Type: Infrared,Capacitive

Type: LCD

application: Indoor,Outdoor

aspect ratio: 16:0

brightness: 600

color: CUSTOM

function: SDK

installation type: Custom

ip rating: NO

lifespan (hours): 60000H

media available: EDA/CAD Models

model number: W21.5

place of origin: Guangdong, China

resolution: 2K/4K

response time: 2S

specification: Strech Bar,Video Wall,Kiosk,Touch Screen

supplier type: ODM

use: Exhibition Hall,Self-Service Business,Welcome Display,Display Of Dishes,Shopping Mall,Retail Store,Advertising Publish

view angle（h/v）: 178

warranty: 1 Year

Product Paramenters

FAQ

Q1: Can I have samples? A1: Of course, you can get our existing samples or customized samples. Q2: You can do OEM service

A2: Of course, we professionally service OEM orders. After you send us pictures or samples, we will try our best to meet your requirements. Q3: What is the resolution of the screen? A3: 1920*1080 (2K) 3840*2160(4K). Q4: What kind of system is the screen? A4: The screen supports Android 7.1 system memory 2G+16G, windows10 system memory 4G solid state 128G Q5: How to control screen content replacement? A5: The screen supports remote CMS remote software. Q6: Can I get product design drawings? A6: Of course, you can get our screen design drawings. Q7: How does the screen get quality assurance? A7: We will repair the screen for free within 1 year and replace the accessories. Q8: How long will the lead time of the screen take? A8: 2-day delivery for regular screens, 8-10 days for customized screens.

Products Description

Ultra-thin LCD screen 9mmLCD digital signage advertising machine module

Smart ultra-thin display Ultra-thin LCD screen 9mmLCD digital signage advertising machine module 55 inches 7KG Indoor advertising player Light design Totem Advertising Vertical LCD kiosk 1500 brightness sunlight readable USB play pictures and videos

Brand	AUO/BOE	Features - Wide View Angle - Ultra Hight Brightness - White LED Backlight, with Built-in LED Driver - Wide Aspect Ratio - High Color Gamut - ultrathin
Size	21.5 inch
Resolution	1920(RGB)x1080, FHD
Display Mode	VA, Normally Black
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Contrast Ratio	5000:1 (Typ.) (TM)
Response Time	25 (Typ.)(Tr+Tf) ms
Display Color	16.7M (RGB 8 bits)
Surface Treatment	Anti-Glare, 3H
Display Area	476.64(H)x268.11(V) mm
Module size	495.6(W)x292.2(H)x24.05(D) mm
Luminance	600-1000 cd/m² (Typ.)
Backlight Type	WLED, 50k Hours, with LED Driver
Input Voltage	5.0V (Typ.)
Interface	LVDS (2 ch, 8-bit), 30 pins Connector
Operating temperature	-10 ~ 80 °C
Storage temperature	-20 ~ 80 °C
Weight	1.63kg
